product introduction
：
hot rolled coil plate on the slab (mainly for the continuous casting billet) as raw material, after heat made strip roughing and finishing mill group. from finishing the last hot steel strip mill out through laminar flow cooling to the set temperature, which consists of the winder coil, steel coil after cooling, according to the different needs of users, with different finishing line (flat, straightening, transverse or longitudinal cutting, inspection, weighing, packaging and logo, etc.) and become a steel plate, flat roll and longitudinal cutting steel strip products. due to the strip steel products with high strength, good toughness, easy to processing molding and good weldability and other excellent properties, and therefore is widely used in ship, automobile, bridges, buildings, machinery, pressure vessels and other manufacturing industries.
main product material: plain carbon steel ss400, q235b, low alloy structure steel q345 (b ~ e), just strength structural steel q420, q460, q550, q690 boiler vessel steel q235r, q345r, bridge steel q345q (c - e)/high-rise building steel q345gj (b ~ e), car girder plate h510l, h610l, h700, pipeline steel x52, x60, x70 and x80.
products are mainly used
are widely used in oil drilling, gas welding tube, liquefied petroleum gas cylinders and other fluid conveying pipe with similar requirements; auto longeron, girders, beams and chassis parts, stamping parts such as wheels; container, buildings, vehicles, tower and other corrosion resistant components, engineering machinery, large-scale railway bridges, etc.
product specification ：
| product | hot rolled coil | flat/volume classification steel coil | transverse steel plate |
| thickness mm | 1.2~25.4 | 1.2~6.5/1.2~12.7 | 5~25.4 |
| breadth mm | 900~2130 | 1000~2130 | 1000~2130 |
| weight t | max 40 | max 40 | 10 |
| inside diameter (length) mm | φ610~762 | φ762 | 2000~12000 |
| outside diameter (length) mm | max φ2150 | max φ2150 | 2000~12000 |
